    Product Details:

    Place of Origin: Dongguan
    Brand Name: DahoMeter
    Model Number: DH-DIN

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: USD999 to 1999 per set
    Packaging Details: standard exporting package
    Delivery Time: 5 to 8 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Usage: DIN Abrasion Tester Roller Diameter:: φ150mm
    Roller Length:: 460mm Rotate Speed:: 40rpm
    Testing Before Delivery: Yes After-sale Customer Service: Yes

    DIN Leather Abrasion Resistance Tester , Shoe Soles DIN Abrasion Tester , DIN Abrasion Test Method



    Applicaion

    Suitable to determine the wear resistance of elastic material, rubber, tires,conveyor belts,shoe soles, soft synthetic leather and other materials.



    Principle

    Under a predetermined contact pressure and a given area ,the specimen with sandpaper angled to measure

    abrasion resistance of the specimen subjected to rubbing on a certain level of sandpaper, sandpaper affixed

    to the surface of the drum, samples pressed on a drum with sandpaper, and the specimen along the roller to

    the lateral movement, abrasion resistance is produced at one end of the cylindrical specimen, tests the value

    of the mass loss of the specimen, by the density of the specimen to calculate the amount of volume abrasion.



    Specifications

    Roll diameter 150mm
    Fixture lateral displacement 4.2mm/hoop each lap
    Rooling speed 40rpm
    Volume 95*66*31cm
    Weight 50kg
    Power 220V 50HZ



    DIN Leather Abrasion Resistance Tester , Shoe Soles DIN Abrasion Tester , DIN Abrasion Test MethodDIN Leather Abrasion Resistance Tester , Shoe Soles DIN Abrasion Tester , DIN Abrasion Test MethodDIN Leather Abrasion Resistance Tester , Shoe Soles DIN Abrasion Tester , DIN Abrasion Test MethodDIN Leather Abrasion Resistance Tester , Shoe Soles DIN Abrasion Tester , DIN Abrasion Test Method
