Fabric Abrasion Test Machine, Martindale Tester, Martindale Testing Equipment, Martindale Abrasion Testing Machine
Apparatus Purpose
The Martindale Abrasion Tester is an ideal and advanced instrument to be used for determination of the abrasion resistance of textile fabrics. Fabrics of all types may be tested by this unit, including woven, non-woven, and knit apparel fabrics, household fabrics, industrial fabrics, and floor coverings, with fabric pile depth of less than 2mm.
This machine have four sample clamp, can testing four sample at the same time. Via motor drive land out in motion friction device under certain load doing reciprocating friction testing determine the effect of the abrasion.To judge the level of sample and provide reference data for material selection.
Applicable Standards
ISO 5470
ISO 12945-2
ISO 12947-2
Specification
| Station |
4 station |
| Outer shaft |
47.5±2.5r/min |
| Inner shaft |
44.5±2.4r/min |
| Count display |
a. Estimated counting: 0~999999
b. Total counting: 0~999999
|
| Pilling specimen tackling |
155g |
| Dimension |
540*640*380mm |
