Place of Origin: | Guangdong, China |
Brand Name: | DahoMeter |
Certification: | ISO,CE |
Model Number: | MHRS-45 |
Minimum Order Quantity: | one set |
---|---|
Price: | negotiable |
Packaging Details: | standard exporting wooden package |
Delivery Time: | 3 to 7 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 300 sets per month |
Measuring Range: | 1.70-94HR15N, 42-86 HR30N, 20-77 HR45N, 60-93 HR15T, 2.29-82 HR30T, 10-72HR45T | Test Force: | 3.147.1,294.2,441.3N,(15,30,45kgf) |
---|---|---|---|
Maximum Allowable Height Of The Sample: | 210mm | Hardness Resolution: | 0.5HR |
Application range:
Rockwell determination of Rockwell hardness of ferrous, non-ferrous and non-metallic materials:
Rockwell hardness measurement for quenched, tempered and other heat-treated materials.
Surface Rockwell determines the surface Rockwell hardness of ferrous metals, alloy steels, hard alloys and metals after surface treatment (carburization, oxidation, electroplating layers);
Especially suitable for the precision measurement of parallel planes.
Main features:
Test process automation, no artificial operation error.
Touch screen LCD display, menu operation, complete functions (data processing, hardness conversion, etc.).
Automatic digital display, no artificial reading error.
Random printer to print hardness test results. Equipped with RS232 data interface.
Accuracy in accordance with GB/T230.2 ISO 6508-2 and U.S. ASTM E18.
Main technical specifications:
1. Measuring range: 70-94HR15N, 42-86 HR30N, 20-77 HR45N, 60-93 HR15T, 29-82 HR30T, 10-72HR45T
2. Test force: 147.1,294.2,441.3N,(15,30,45kgf)
3. Max. height of specimen allowed: 210mm;
4. Distance from the center of the indenter to the wall of the machine: 165mm;
5. Hardness resolution: 0.5HR.
6. Dimension: 466x238x630mm;
7. Weight: about 105kg
Standard configuration:
Large platform: 1 set.
Diamond indenter: 1 set.
Small platform: 1 set.
116 steel ball indenter: 1 set.
V-type test bench: 1 set.
Printer: 1 set.
Standard surface Rockwell hardness block: 4 pcs.
