DahoMeter Original Factory Solid Liquid, Powder Specific Gravity Meter Price, Specific Gravity Testing Equipment DE - 120T
Application: It is suitable for the field of quality management,cost control,new formula
researching,new materials researching, scientific academies, researching key laboratories,quality inspection.dye,bleach,leather,glaze,clay suspension.,etc industrial.
Standards: According to the ASTM D792,ASTM D297,GB/T1033,GB/T2951,JIS K6268,ISO 2781,ISO 1183,GB/T11540,GB/T12206,GB/T5518 standards etc.
DE-120T can measure the density of solid and liquid; Features of simple operation,wide application,fully function; alarm rings when judge density is unqualified through the top and bottom limitation setting.About the solid mode,function of measuring DIN volume abrasion loss and expansibility of rubber,actual density and apparent density of powder,oil content of oil bearing,density of high density products.etc. adopt the memoryless dynamic measurement method for liquid mode; function of measuring density with three mode,get out of the cumbersome operation of re-calibrate when change weight. Function of displaying concentration,density and baume.
Specifications:
Density resolution: 0.0001 g/cm3
Maximum weight:120g
Minimum weight: 0.001g
Measurement range: 0.0001-99.9999g/cm3
Features:
(1)No need to open and close the lid,simple operation,shorter time measuring,according to the specification of new materials laboratory.
(2)Show the percentage composition of mixed samples for researching and developing new materials.
(3)Automatically judge whether density is qualified or not;prompt alarm.
(4)Function of solution compensation.either liquid or water can be used as medium.
(5)Function of setting actual water temperature,measuring medium density,and water proof medium density.
(6)Function of setting aerostatic buoyancy and the bound of density.
(7)Adopt the completed high-capacity measurement accessories with the transparent injection mould tank,which can resist wear,fall off,and corrosion.
(8)Density value of samples with the temperature from normal to 100 centigrade can be measured.
(9)Take samples conveniently;50CC or less would be okay.
(10)It is very easy to clean the measurement cup,and can’t got the limitation of the size of pycnometer caliber.
(11)Volatile liquid,corrosivity liquid,vicidity liquid,strong acid and strong lye liquid can be measured quickly.
(12)Adopt the completed special windproof and dustproof cover,which makes the structure convenient and durable.
(13)Interface of RS-232C is included.the printer of DE-40 will be available to connect PC with instrument.
Measurement procedure of solid model:
- Place the sample on the test board to measure the weight in the air,and then press the ENTER button to memory.
- Place the sample into the water to measure the weight,and then press the ENTER button to memory.show the density value.
Measurement procedure of liquid model:
- Place breaker with samples on testing board.and take off the weigh of pothook.
- Make standard weigh hanged on the pothook and submerged in the liquid to be test totally.and then press the ENTER button to memory.Density valuve can be displayed.
Measurement procedure of hydroscopicity products(porosity products)
- Place the sample on the testing board to measure the weight in air,and then press the ENTER button to memory.
- Place the sample that did the waterproof treatment into water to measure the weight in water,and then press the ENTER button to memory.show the density value.
Instruction Table
| brand |
DAHOMETER |
| model |
DE-120T |
| density resolution |
0.0001 g/cm3 |
| Weight range |
0.001~120g |
| Density range |
0.0001—99.9999g/cm3 |
|
Solid
mode
|
Measuring solid items |
Density of all forms of solid,including metal,rubber,plastic,film,floating body,powder,foam,viscous body,structure,tubing,wood,sponge,glass,pitch,cement,soil,gem,paper,concrete,graphite,coal,rock,ceramic.etc.(cover the products of
hydroscopicity,non-absorbency,high – viscosity)
|
| Measuring mode |
Archimedes principle
A.general solid measuring method B.porosity materials saturation mode C.porosity materials surface covering method mode.
D.professional constant volume mode method E.professional rubber abrasion loss and expansibility mode method F.professional hydroscopicity mode method G.professional oil length mode method
|
| Measurable project |
density of general non-absorbency solid
density of porosity materials
oil length of oil bearing
porosity of porosity materials
DIN volume abrasion loss of rubber
powder density
water absorption rate
|
|
Measuring time
|
About 5 seconds |
| Memory method |
memory in shorter time by one procedure |
| Specific gravity measurement frame |
unicase injection forming professional specific gravity mesaturement frame
(size:length13.5mm×wide5mm×high11.6mm)
|
| Measurement tank |
unicase injection forming transparent professional measurement tank
(size:length16.9mm×wide9.8mm×high8.3mm)
|
| Result disply |
Disply according to the model:density,specific gravity,apparent density,volume density,wet density,total porosity,effective porosity,oil content,water absorption,wear loss,wear index,expansibility,volume and so on. |
| Funtion setting |
Water temperature setting,density setting of medium of comparative solution,density setting of medium of waterproofing treatment ,boung setting,aerostatic buoyancy setting,
Loss value setting of fixed weight of reference glue,loss value setting of weight of reference glue,density setting of reference glue.
|
|
Mixed
material percentage
|
Function introduction |
automatically read the percentage of the main material in the two kinds of mixed materials |
| setting |
freely set the density value of main material and subordinate material |
| disply |
density value,percentage of main material |
|
liquid
mode
|
Measurement type |
a:mobility liquid,vicidity liquid,volatile liquid,corrosivity liquid,high temperature liquid,suspension liquid,emulsion and so on.
b:alcohol,scaling
powder,essence,blood,sodium chloride,glycerol,electrolyte,diesel,refrigerating,hydrofluoric
acid,dichloromethane,vitriol
|
| Measurement principle |
Archimedes principle displacement method |
|
Measurement
mode
|
3 group |
| Measurement time |
about 5 seconds |
| Memory mode |
memory in shorter time by one procedure |
| Result disply |
Density and baume |
|
Specific
Gravity
Measurement
frame
|
stainless steel specific gravity measurement frame |
| Function setting |
Temperature setting,density setting, measurement weights setting of standard sensor ball and weights setting in the water |
|
Measurement
testing
|
distilled testing |
|
Calibration
mode
|
auto correction with one button,auto detection. |
| Output mode |
standard interface of RS-232,output and
Print testing data conveniently
|
| Standard accessories |
Host,tank,test board,tweezers,thermometer,100G weight,wind and dust cover,a set of measuring floating body parts ,power transformer,DE-20A standard liquid measurement assembly |
| Optional accessories |
DE-40 printer,DE-20B anti corrosive liquid measurement assembly |
| power |
AC100V - 240V |
| Main feature |
data display,accuracy,speediness,convenience
Durable,economy
|
