*With PC software, can check and print testing results on computer;
*Suitable for measuring metal (such as steel, cast iron, aluminum, copper, etc.), plastic, ceramic, glass, glass fiber and other any good conductors of ultrasound;
*Can be equipped with a variety of different frequency, chip size, double crystal probe use;
*Have probe zero calibration, a two-point calibration function, can be automatically on system error correction;
*Thickness can be known the sound velocity measurement, in order to improve the accuracy of measurement;
*With functions of coupling status alert;
*With LED backlight, convenient to use in dark environment ;
*Battery indicator function, real-time display remaining power;
*With automatic power saving function dormancy, automatic shutdown etc;
*Small, portable, high accuracy, suitable for bad operating environment, vibration, impact resistance and electromagnetic interference.
Technical Parameter
Measuring range:0.75~300mm (0.03~11.8inch) depends on probe;
Temperature available:-10℃~60℃;
PC connecting and software:NO;
Sound velocity range:1000~9999m/s (0.039~0.394in/us);
Display resolution:0.01mm or 0.1mm(lower than 100.0mm) 0.1mm(more than 99.99mm);
Accuracy:±(0.5%Thickness+0.04)mm,depends on Materials and conditions;
Data Memory:5 files(up to 100 values for each file)of stored values 5 Sound Velocity of stored values;
Power:2pcs 1.5V AA size,batteries. 100 hours typical operating time(LED back light off) ;
Continuous working time:250 hours (with backlight off);
