High Precision Brinell Hardness Testing Machine, Automatic Digital Brinell Hardness Tester
It's suitable to determine Brinell hardness of black metal, non-ferrous metals and bearing alloy material;
Wide range of applications, suitable for precision measurement of parallel planes, and the surface measurement is stable and reliable.
►Features
- Solid structure, good rigidity, accurate, reliable, durable, high test efficiency;
- Mechanical reversing switch, high power solid state relay;
- High precision measuring system;
- Widely applicable to quality control in the production field, strong adaptability to working environment;
- Patent design of mechanical structure, low noise, very low failure rate;
- Accuracy is in line with GB/T231.2, ISO6506-2 and E10 ASTM standards in the United States;
- Wide range of applications, suitable for the precision measurement of parallel planes, and stable and reliable surface measurement.
►Patameter
| Measuring range |
8-650HBW |
| Test force |
1838.8,2415.8,7355.3,9807,29421N
(187.5, 250, 750,1000,3000kgf)
|
| Max. height of test piece |
230mm |
| Depth of throat |
120mm |
| Power |
AC380V /50HZ |
| Dimension |
700 x 268 x 842mm |
| Weight |
approx. 210kg |
