DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type

DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type

    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
    • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type
  • DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type

    Product Details:

    Place of Origin: Dongguan
    Brand Name: DahoMeter
    Model Number: DX-800

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: negotiable
    Packaging Details: exporting standard wooden package
    Delivery Time: 5 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Warranty: 1 Year After-sale Service Provided: Yes
    Testing Before Delivery: Yes OEM Service: Yes
    Usage: XRF Gold Spectrometer Detector Type: Proportional Counter Tube
    Relative Humidity: 15% ~ 90%

    DX-800 XRF Precious Metal Analyzer, XRF Gold Spectrometer For Gold Purity Testing Multi Elements Type





    At present, the use of XRF analyzer for chemical composition analysis and purity determination of precious metals has become a widely used, extremely popular, and supported by national standards, and reliable methods. The use of XRF for the analysis of precious metals is a faster and more economical method of multi-element detection than spark test and chemical reagent testing.



    The XRF Analyzer provides users with an easy-to-use, cost-effective inspection technology: no need to inspect the tool into the material of the sample being tested, or damage the sample. The chemical composition information of the alloy can be obtained.thus determines the carat rating of the sample. Whether you are buying precious metals such as gold, selling or producing jewelry, making metals, or recycling used metals, you need a quick way to determine the carat grade and other precious and non-precious metal content with extreme precision. In the first time, to effectively control product quality, set a reasonable price. The xrf analyzer quickly provides accurate analysis of all types of samples.





    Advantages and Characteristics of Analysis



    • Integrated an inbuilt computer with high industrial motherboard and multi- point hand touch, you don’t need to prepare other computers, it can bring you super smooth experience feelings
    • Three core components inside the instrument are all imported, so it determines that the instrument can accurately distinguish different gold samples especially 99.9% gold and 99.99% gold
    • The instruments possess own unique mode of “one-key test”, it is China first and same as Europe's top spectrometers. No matter any unknown metal material, the operators don’t need to choose test templates and software intelligently matches the best way to measure and calculate. They are capable of fast, precise and non-destructive metal testing, making them suitable for use by jewelry retailers, jewelry manufacturers, precious metal refineries, pawn shops, government quality inspection departments, banks, laboratories and tertiary institutions
    • Super long warranty, confidence comes from pure European spectrometer production technology
    • The instruments have an innovative function that can help customers identify gold-plated samples
    • The users can see sample test position accurately by camera and cabin lighting system, and it can improve the testing confidence of users
    • Equipped with a variety of optical collimator, breakthrough solved test problems of tiny metal samples (such as spun gold and gold thread samples)
    • We can download and upload test data from network, and it is easy to view and share test results
    • Temperature drift rate of all the parts inside instrument is controlled within one over one million, ensuring the strong stability and high precision of instrument. Testing results can show 4 digits after the decimal point, beyond all domestic spectral type precious metals analyzer
    • Ultrahigh resolution, Super clear camera, Super convenient operation, Super fast detection speed, Perfect human interface



    Application and Examples



    Accurate analysis of precious metals Au, Pt, Ag, Pd

    On-site gold level identification of gold: 0-24 kt

    Check the gold content in scrap metal

    Identifying impurity materials

    Identify unknown metals



    Hardware Performance and Advantages

    High-resolution, high-definition camera, convenient operation, fast detection speed, user-friendly interface



    Instrument Performance and Configuration



    Brand DahoMeter
    Model DX-800 DX-800M DX-2800 DX-2800M
    Computer Built In No Yes Yes Yes
    Detector Type Proportional Counter tube Si-pin (USA) SSD(USA)
    Multichannel Analyzer Digital multichannel DahoMeter-DMCP
    Sample Chamber Size 300 *300 *100 (mm) 280 *280 *90 (mm) 380 * 380 * 60 (mm)
    Test Time 10sec ~ 100sec 5sec ~ 30sec
    Measuring Element

    Au Ag Pt Pd Cu Ni Zn Rh Cd Ru Fe Co Ir W Os Pb (16 elements )

    Au, Ag, Pt, Pd, Cu, Mo, Mn ,Ga,Co ,Ir(Ir≥5%)

    72 elements from sodium (Na) touranium (U) between all the elements
    Analysis Range 0.01% to 99.99% 1ppm to 99.99%
    Accuracy

    0.05% ~ 0.1%

    0.1% (Au≥96%)

    0.03% (A≥96%) 0.01% (Au≥96%)
    Sample Form Solid, powder, liquid
    Tube Voltage 5KV ~ 50KV
    High Voltage Power Supply 0 ~ 50KV
    Camera HD camera
    Filters Selectable customized switches
    Analysis Software Qualitative and quantitative analysis software
    External Dimensions 450 * 400 * 290 (mm) 410 * 390 * 280 (mm) 480 * 480 * 390 (mm) 480 * 480 * 390 (mm)
    Weight 33Kg 30Kg 38Kg 38Kg
    Instruments Environmental Requirements
    Ambient Temperature -5 ° C ~ 40 ° C (Suggested that in air conditioning room)
    Relative Humidity 15% ~ 90%
    Power Requirements AC 220V ± 5V, 50/ 60 HzNo high power electromagnetic and vibration interference sources nearby
