XRF Analyzer for Gold , Silver , Copper , Platinum , Palladium Testing Machine , Spectrometer Precious Metal Analyzer
Application
pawnbroking,jewelry industry,banking industry,jewelry testing center,mining industry,precious metal recycling,precious metal materials researching laboratory.,etc.
Specification:
Analysis Range 1ppm to 99.99%
Accuracy RSD ≤ 0.1%
Sample Form Solid, powder, liquid
Tube Voltage 5KV ~ 50KV
High Voltage Power Supply 0 ~ 50KV Spellman (USA)
Camera HD camera
Filters Selectable customized switches
Detector Type Proportional Counter tube
Multichannel Analyzer KEY-DMCP
Sample Chamber size 310 * 280 * 60 (mm)
Test Time 10sec ~ 100sec
Elements of Interest Precious metal Au, Ir, Ag, Pt, Pd, Ru, Rh, Os, etc.
Basic metals W, Cr, Mn, Fe, Co, Ni, Cu, Zn, Cd, Sn, Pb, etc. (Na ~ U)
Analysis Software KEY-FP qualitative and quantitative analysis software
External Dimensions 380 * 372 * 362 (mm)
Weight 30Kg
Instruments Environmental Requirements:
Ambient Temperature -5 ° C ~ 40 ° C (Suggested that in air conditioning room)
Relative Humidity 15% ~ 90%
Power Requirements AC 220V ± 5V, 50/ 60 Hz
No high power electromagnetic and vibration interference sources nearby
