    Product Details:

    Place of Origin: Dongguan
    Brand Name: DahoMeter
    Model Number: DH-XD-80

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: USD499 to 6999 per unit
    Packaging Details: standard exporting wooden package
    Delivery Time: 5 to 8 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Usage: Xenon Aging Testing Chamber Testing Before Delivery: Yes
    After-sale Customer Service: Yes

    Lab Sun Simulation Accelerated Xenon Lamp Aging Testing Chamber / Machine / Oven / Cabinet / Equipment




    Application:



    By using the xenon lamp to simulate sunlight,and condensation of moisture to simulate rain and dew.put the testing specimen under sunlight at some temperature and humidity alternant cycle program to do the testing.the machine can help to show the bad effect on specimen from outdoor environment in short time with several days or weeks instead of years.The testing data can help to choose more suitable materials.and improve existed materials.and evaluate the changing of formula how to effect the durability of products.





    Features:



    1.Adopt the long axis fan motor,anti high and low temperature stainless steel multi-blades wheel,have good convection.and vertical diffusion cycle.



    2.Double-layer anti-high temperature sealing strip has been used between the door and the box.to make sure the leakproofness for the testing area.



    3.Adopt non-counteractive door knob,more easy operation.



    4. Adopt high quality fixable PU running wheel of the bottom of machine.



    5.Adopt multi-layer hollow tempered glass inspection window.(can observe the testing procedure clearly)



    6.Irregular shape sample holder,make the installation of testing specimen more easier.and convenient to be used.



    7. The working life of xenon lamp is determined by the radiation level.normal service life of lamp is 1600 hours.Lamp is easy to be changed.The effective filter can make sure spectrum demanded can be offered.





    Specification:



    Model DH-XD
    -80 -150 -225 -408 -800 -1000
    Inner size: WHD(cm) 40*50*40 50*60*50 60*75*50 60*85*80 100*100*80 100*100*100
    External size: WHD(cm) 105*185*115 105*185*115 115*195*115 135*210*120 155*230*145 155*230*165
    Temperature and humidity uniformity ± 2°C; ± 3%RH
    Temperature range 0℃~80℃, adjustable
    Humidity range 30%~98%R.H
    Type of light source imported air-cooled full solar spectrum long arc xenon lamp (average service life is around 1600 hours)
    Rainfall time 1~9999min, adjustable
    Rainfall cycle 1~240min,interval is adjustable
    Wavelength 290nm~800nm
    Source irradiance 290~800nm: 100~600w/m2
    300~890nm: 200~1200w/m2
    340nm: 0.3~1.2w/m2
    420nm: 20~120w/m2
    Distance from the center of the arc to the sample holder 350~380mm
    Sample rotating basket speed ≥1r/min
    Water spray cycle Water spray time: 0 ~ 99h59min, continuously adjustable; Stopping time: 0~99h59min, continuously adjustable
    Light time Continuous programming
    Blackboard temperature 85±3℃
    Cooling method Mechanical refrigeration air cooling
    Xenon lamp light Xenon long-arc lamp, 1.8KW±10%, 290-800nm, 1200W/m2
    Xenon lamp light quantity 1PCS 2pcs 3 PCS
    Box material Stainless Steel SUS304#
    Control and cooling system Korea TEMI programmable controller
    Power (w) 4500 5500 6000 11800 13500 14000
    weight (kg) 230 230 300 450 550 680




    Lab Sun Simulation Accelerated Xenon Lamp Aging Testing Chamber / Machine / Oven / Cabinet / EquipmentLab Sun Simulation Accelerated Xenon Lamp Aging Testing Chamber / Machine / Oven / Cabinet / Equipment
