    Product Details:

    Place of Origin: Dongguan
    Brand Name: DahoMeter
    Model Number: DH-MI-BP

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: USD999 to 1999 per unit
    Packaging Details: Standard wooden exporting package
    Delivery Time: In stock
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Usage: Melt Flow Indexer Testing Before Delivery: Yes
    After-sale Customer Service: Yes

    Plastic Melt Flow Rate Index Tester, MFI Testing Device, Melting Point Apparatus, Melting Point Testing Machine





    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

    Main technical parameters



    • Temperature range: 0 ℃ -400 ℃
    • Double heating ring, double P100 temperature monitoring system (for HT-3682VM-7PT)
    • Temperature display resolution: 0.1 ℃
    • Temperature accuracy: ± 0.2 ℃ (HT-3682VM-7PT: ± 0.2 ℃)
    • Temperature uniformity:

    ± 0.5 ℃ (HT-3682VM-7PT: ± 0.2 ℃)

    • Volume timing resolution: 0.001S,Accuracy:0.01S
    • Chinese GB / 3682-2018S standard die / half die diameter: Φ2.095 ± 0.005mm / Φ1.050mm ± 0.005mm; die length: 8.000 ± 0.025mm / Φ4mm ± 0.025mm(half die is optional)
    • American ASTM D1238 standard die / half die diameter: Φ2.0955 ± 0.0051mm / Φ1.048mm ± 0.005mm; die length: 8.000 ± 0.025mm / Φ4mm ± 0.025mm
    • Loading barrel diameter: Φ9.550 ± 0.007mm; length: 152 ± 0.100mm
    • Piston rod head diameter: Φ9.475 ± 0.007mm, length: 6.350 ± 0.100mm
    • Weight accuracy: ± 0.5%
    • Japan Omron photoelectric rotary displacement measurement sensor
    • Mold material: tungsten carbide
    • Displacement measurement

    accuracy: 0.01mm

    • Test load: 2160g
    • Countdown: 300s
    • Melting index temperature: 230 ℃
    • Volume method test range:

    0.1-3000cm3/10min(displacement measurement)

    • Measuring range of melt-blown material mass method: (0.1 ~ 2300) g/10min(displacement measurement)
    • Measurement range of non-melt spray material mass method: (0.1 ~ 100)g/10min (cutting measurement)
    • Output mode: Mini automatic printout
    • Power supply voltage: AC220V ± 10% 50HZ or AC110 / 600HZ; choose different power supply voltage according to the country of use
    • Weight: 60kg
