Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap

Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap

    • Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap
    • Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap
    • Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap
  • Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap

    Product Details:

    Place of Origin: Dongguan China
    Brand Name: DahoMeter
    Certification: ISO,SGS
    Model Number: ANL-P1

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiable
    Packaging Details: standard exporting package
    Delivery Time: 5-7 DAYS
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Color: White Name: Bottle Lid Torque Meter
    Power: 7.2V 1.2VX6 Ni-MH Battery Group

    Torque Measuring Machine , Torque Testing Equipment , Torque Measurement Instrument for Bottle Cap


    Torque Measuring Machine, Torque Testing Equipment, Torque Measurement Instrument for Bottle Cap

    Function:
    Digital displaying torque tester is for measuring all kinds of torque of cap of bottle.it is mainly applicable to test and calibrate tightening force,torque destructive testing for accessories;it has the feature of easy operation,high precision,full-function,convenient carrying.,etc.It is widely used in the fields of electric,light industry,machinery manufacturing,scientific research institution.,etc.

    Specification:

    Measuring range / Division value:
    N.m 20.00/0.01
    Kg.cm 204.0/0.1
    Lb.in 177.0/0.1
    Accuracy:+-1%
    Peak Value Sampling Frequency:1920 HZ
    Power:8.4V 1.2VX7 Ni-MH Battery group
    Charging Time:4~6 Hours
    Continuous using time of battery:About 10 Hours
    Battery life:>=300 times
    Size:400mm*200mm*200mm
    Net Weight:12kg
    Power adapter:Input:AC 220V 50HZ Output:DC 10V 300mA

    Feature:
    • High precision,high resolution,high sampling rate,full screen.
    • Adopting high precision torque sensor,displaying direction of torque.
    • Limitation value of upper and bottom can be set;red-green indicator light;buzzer and sound-light alarm.
    • Three units can be switched,can choose(N.m;Kgf.cm;Ib.in)
    • Three mode of real time,peak,automatic peak can be switched casually.
    • Adopt USB interface and PLC communication,synchronously testing function,can be connected to computer,testing force curve and record of details of testing force can be displaying synchronously,Also can be stored,printed,and did analysis.
    • Function of keeping peak,automatic relief,and relief the free setting of time.
    • Large memory space,can store 99 units of testing data.
    • Function of turning off automatically without operation.free setting of time.



    Operation Surroundings:
    Temperature:-10 degree to 40 degree
    Humidity:<=90% RH
    No vibration,no corrosivity
