MFI Tester Melt Flow Index Testing Machine for Mask Non-woven Plastic PP Polypropylene

Product Details:

Place of Origin:	Dongguan China
Brand Name:	DahoMeter
Certification:	ISO,SGS
Model Number:	DH-MI-VP

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	standard exporting package
Delivery Time:	3 DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300 sets per month

Contact Now

Detailed Product Description

Display Resolution::	0.1 °C	Loading Cylinder Diameter:	Φ9.550±0.007 Mm
Loading Cylinder Length:	152±0.100 Mm	Product Name:	Melt Flow Index Testing Machine
Testing Method:	MVR	Testing Before Delivery:	Yes

MFI Tester Melt Flow Index Testing Machine for Mask Non-woven Plastic PP Polypropylene

Hongtuo melt flow index extrusion plastometer applies to both molten high temperature of the PE, gather fang PSF, fluorine plastic, nylon engineering plastic, also suitable for polyethylene, polypropylene polystyrene, ABS resin, pom resins melting temperature lower plastic tests.

Meet the standards: ASTM D 1238, ISO1133, GB/T3682

Characteristic:

1. Hongtuo melt flow index extrusion plastometer using advanced electronic measurement technology, liquid crystal display test results, the micro printer output results and calculating the quality of the melt flow rate (MFR) or melt volume flow rate (MVR) (note: single determination value and many times the average of the cutting material).
2. Tester compact structure, beautiful, the control system can real time measurement and display temperature numerical, has the upper limit temperature protection, constant temperature sound reminders, response time tip etc. Function. The use of advanced PID control technology and high speed and high resolution sampling circuit, make the machine in constant temperature is the following characteristics:
A: heating speed, the dinky overshoot.
B: constant temperature and high precision.
C: in the packing after, can quickly restored constant temperature condition.

Specification:

Model:	DH-MI-VP
Testing method:	Quality method, volume method
Display:	Liquid crystal display
Time precision:	0.01S
Cut material way:	Automatic sample cut
Temperature range:	100~450°C
Controll accuracy:	±0.5°C or better
Testing range:	1.0~100g/10min,0.01~350cm³/10min
Recovery time:	<4min
Loading method:	Manually loading
Displacement measurement accuracy:	±0.1mm
Temperature resolution:	0.1°C
Power:	(220-15%~220+10%)VAC 50Hz 500W Single phase three line
Output:	Micro printer

MFI Tester Melt Flow Index Testing Machine for Mask Non-woven Plastic PP Polypropylene
