    Product Details:

    Place of Origin: China
    Brand Name: DahoMeter
    Certification: FCC,CE
    Model Number: KR-220

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: USD499 to USD1299
    Packaging Details: standard exporting package
    Delivery Time: 5-7 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Usage: Digital Surface Roughness Tester Testing Before Delivery: Yes
    After-sale Customer Service: Yes

    Portable Surface Roughness Measuring Instrument, Digital Portable Surface Roughness Tester Leeb432

    Product Application

    It is applicated to measure surface roughness of various machinery-processed parts, especially for roughness measurement of complex parts,such as:Flat, Curved surface, Grooves and Holes.Capable of evaluating surface textures with a variety of parameters according to various national standards and international standard.
    The measurement results are displayed digital/graphically on the LCD, and output to the printer.



    Main Features

    *Electromechanical integration design, small volume, light weight, easy to use;
    *Using DSP chip to control and data processing, high speed, low power consumption;
    *128 x 64 OLED dot matrix display, digital / graphic display; highlight no perspective;
    *Intuitive and rich display information, can display all the parameters and graphics;
    *Compatible with ISO, DIN, ANSI, JIS national standards;
    *Residual quantity icon, prompting the user to charge;
    *Continuous working time: more than 20 hours.
    *Real-time clock settings and display, convenient data recording and storage.
    *With automatic dormancy, automatic shutdown and power saving function
    *Reliable control motor to go dead circuit and software design
    *Measurement information display, menu prompt information, false information and switch machine and other tips that information;
    *Can be connected to a computer and printer;
    *Optional different sensor, measuring platform, mini printer, extension rod and other accessories.
    *Plastic shell, inspired by “TRANSFORMERS” stylish design, portable, high reliability.
    *Optional bluetooth function.
    *High price performance.





    Technical Parameter

    20 roughenss parameters Ra,Rz,Rq,Rt,Rp,Rv,R3z,R3y,RzJIS,Rsk,Rku,Rsm,Rmr,Rx,RPc,Rk,Rpk,Rvk,Mr1,Mr2
    Measuring Range Ra: 0.005~16.000μm Rz: 0.02~160.00μm
    Sample Length 0.25, 0.80, 2.50mm
    Evaluation Length (1~5)L
    Maximum Drive Stroke 17.5mm/0.7inch
    Indication Accuracy 0.001μm
    Accuracy ≤(±10)%
    Repeatability <6%
    Data Storage 100 groups
    Power Rechargeable Li-battery
    Relative Humidity <90%
    Working Temperature -20°C~40°C
    Size 158x63.5x46mm
    Weight of Host 0.3kg



    Portable Surface Roughness Measuring Instrument,Digital Portable Surface Roughness Tester Leeb432Portable Surface Roughness Measuring Instrument,Digital Portable Surface Roughness Tester Leeb432Portable Surface Roughness Measuring Instrument,Digital Portable Surface Roughness Tester Leeb432Portable Surface Roughness Measuring Instrument,Digital Portable Surface Roughness Tester Leeb432
