KR-210 Surface Roughness Tester, Surface Roughness Measuring Device, Surface Roughness Gauge Price
MAIN FEATURE
*Full metal shell design, sturdy, compact, portable, high reliability.
*Visual waveform display;
*Electromechanical integration design, small volume, light weight, easy to use;
*Using DSP chip to control and data processing, high speed, low power consumption;
*128 x 64 OLED dot matrix display, digital / graphic display; highlight no perspective;
*Intuitive and rich display information, can display all the parameters and graphics;
*Compatible with ISO, DIN, ANSI, JIS national standards;
*Residual quantity icon, prompting the user to charge;
*Continuous working time: more than 20 hours;
*Real-time clock settings and display, convenient data recording and storage;
*With automatic dormancy, automatic shutdown and power saving function;
*Multi-info Display: measurement information, menu prompt, fault and power switch information indicated.
*With PC software, can be connected to a computer and printer;
*Optional different sensor, measuring platform, mini printer, extension rod and other accessories;
*Support OEM Service, High price performance.
TECHNICAL DATA
| 20 Testing Parameters |
Ra,Rz,Rq,Rt,Rp,Rv,R3z,R3y,RzJIS,Rsk,Rku,Rsm,Rmr,Rx,RPc,Rk,Rpk,Rvk,Mr1,Mr2 |
| Measuring Range |
Ra: 0.005~16.000μm Rz: 0.02~160.00μm |
| Sample Length |
0.25, 0.80, 2.50mm |
| Evaluation Length |
(1~5)L |
| Maximum Drive Stroke |
17.5mm/0.7inch |
| Indication Accuracy |
0.001μm |
| Indication Error |
≤(±10)% |
| Variability |
<6% |
| Data Storage |
100 groups |
| Power |
Rechargeable Li-battery |
| Relative Humidity |
<90% |
| Working Temperature |
-20°C~40°C |
| Size |
141x55x40mm |
| Weight of Host |
0.4kg |
