High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing

High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing

    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
    • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
  • High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing

    Product Details:

    Place of Origin: Dongguan
    Brand Name: Quarrz
    Certification: CE,FCC
    Model Number: DE-120M

    Payment & Shipping Terms:

    Minimum Order Quantity: One set
    Price: USD399 to 1299 per unit
    Packaging Details: Standard exporting package 45*20*36cm
    Delivery Time: stock
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Power Supply: European Type;British Type;Australian Type;American Type Customized: Yes
    Density Resolution: 0.0001g/cm3 Weight Resolution: 0.001g

    Oil Content Tester , Oil Content Meter , Oil Content Analyzer for Oil Bearing DE-120M



    ------High-precision,Outstanding Performance, density resolution 0.0001 g/cm3,

    Appropriate for Small Products.

    High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing



    Application:



    Powder Metallurgy,magnetic Materials,Hard Alloy,Rubber,Plastic,Wire and Cable,Laboratory,Institute of New Materials Researching and Testing.Field of quality management,cost control,formula researching and developing,density test of small products and high-precision products,researchate of mrial density.



    Standards:



    According to the ASTM D792,ASTM D297,GB/T1033,GB/T2951,JIS K6268,ISO 2781,ISO 1183,GB/T208,JB/T7780 standards etc.



    Specification



    Model:DE-120M

    Density resolution: 0.0001 g/cm3

    Maximum weight:120g

    Minimum weight:0.001g

    Measuring range: 0.0001—99.9999g/cm3



    Model:DE-200M

    Density resolution: 0.0001 g/cm3

    Maximum weight:200g

    Minimum weight:0.001g

    Measuring range: 0.0001—99.9999g/cm3





    Features

    (1)No need to open and close the lid; Simple operation;Shorter time; According to the specification of new materials laboratory.



    (2)Show the percentage composition of mixed samples for researching and developing new materials.

    Apply to powder metallurgy,magnetic materials,ceramics,fireproofing materials,

    precious metal and so on.



    (3)Automatically judge whether the sample is qualified or not;prompt alarm.



    (4)Function of solution compensation.necessary if liquid other than water is used as a medium for measurement.



    (5)Function of setting actual water temperature,measuring medium density,and water proof medium density.



    (6)Function of setting aerostatic buoyancy compensation and the bound of density.



    (7)Adopt the completed high-capacity measurement accessories with the transparent

    injection mould sink,which can resist wear,fall off,and corrosion.



    (8)Adopt the completed special windproof and dustproof cover,which makes the instrument convenient and durable.

    Interface of RS-232C is included.the printer of DE-40 will be available to connect PC with the instrument.



    Standard Accessories:

    Host,Sink,Test board,Tweezer,Thermometer,100G weight,Windproof and dustproof

    cover,A set of measuring grain accessories,A set of measuring floating body

    accessories,Power transformer



    Measurement Procedure of Non-hydroscopicity Products:

    (1)Place sample on test board to measure weight in air,and then press ENTER button to memory.



    (2)Place sample into water to measure weight in water,and then press ENTER button to memory.

    Density value is displayed.



    Measurement Procedure of Hydroscopicity Products:

    (1)Place sample on test board to measure weight in air,and then press ENTER button to memory.



    (2)Place sample that did waterproof treatment into water to measure weight in water,and then press ENTER button to memory. Density value is displayed.



    Technical Specification:



    Brand Quarrz
    Model AU-300V AU-600V AU-900V AU-1200V AU-120V AU-200V
    Weight range 0.005~300g 0.005~600g 0.01~900g 0.01~1200g 0.001~120g 0.001~200g
    Standard deviation 0.005g 0.005g 0.01g 0.01g 0.001g 0.001g
    Density readability 0.001 g/cm3 0.0001 g/cm3
    Testing Board ABS injection moulding Aluminum alloy die-casting moulding
    range 0.001~99.999g/cm3 0.0001~99.9999g/cm3
    Oil content resolution 0.1% 0.01%
    Result display Oil content,density,oil total volume,oil volume can be read directly.
    Measuring principle Archimede principle substitution method
    Measuring time Around 10 to 60 seconds
    Opening lid method for testing board Rapid unobstructed without lifting lid design
    Water tank

    Completed injection moulding transparent PC water

    tank(size:length15.3 cm×witdth10.7 cm×height9.3cm)

    Parameter setting

    Water temperature setting,measuring medium density setting,

    lubricating oil medium density setting,air buoyancy setting.

    Calibration method Single key calibration,automatically detection
    Standard components

    (1)host(2)water tank(3)testing board(4)tweezers(5)thermometers

    (6)weight(7)windproof dustproof cover(8)power transformer

    Interface Standard RS-232 interface
    Optional accessories AU-40 printer,data connecting wire
    Power supply AC100V~240V 50HZ/60HZ (Europe standard)
    Gross weight/size 4.5kg/Length42.5 cm×Width17.5 cm×Height32.5cm



    DETAILS:



    High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing

    High Precision Oil Content Density Measurement Instrument Oil Content Meter Oil Content Analyzer for Oil Bearing
