Original Factory Price Expansion Rate , DIN , ARI , Akron , Abrasion Tester , Density Measuring Instrument
Shorter measuring time,Multifunction,0.001 g/cm3 density resolution,Can be applied to porous material.
Application:
Powder Metallurgy,magnetic Materials,Hard Alloy,Rubber,Plastic,Wire and Cable,Laboratory,Institute of New Materials Researching and Testing.Field of quality management,cost control,formula researching and developing,density test of small products and high-precision products,researchate of mrial density.
Standards:
According to ASTM D792,GB/T1033,GB/T2951,JIS K6268,ISO 2781,ISO
1183,GB/T208,GB/T5163,GB/T 1933 standards etc
No need to open and close the lid with the completed aluminum alloy measuring table; Simple operation and conform to the new materials laboratory operation specification; automatically judge whether the sample is qualified or not; Function of warning and measuring the volume abrasion value DIN of rubber,of Akron,and expansibility; Measuring the true density with pycnometer method for powder material; Function of waterproofing treatment with boiling saturation method,impregnated saturation method,vacuum saturation method,surface sealing wax covering method,and surface vaseline covering method,and automatic measuring the porosity,oil content and water absorption; The purity of the main material in two kinds of mixture also can be measured.
Specification:
Mode: DA-300M
Measuring range: 0.001—99.999g/cm3
Minimum weight: 0.005g
Maximum weight: 300g
Resolution: 0.001 g/cm3
Mode: DA-600M
Measuring range: 0.001—99.999g/cm3
Minimum weight: 0.005g
Maximum weight: 600g
Resolution: 0.001 g/cm3
Mode: DA-900M
Measuring range: 0.001—99.999g/cm3
Minimum weight: 0.01g
Maximum weight: 900g
Resolution: 0.001 g/cm3
Mode: DA-1200M
Measuring range: 0.001—99.999g/cm3
Minimum weight: 0.01g
Maximum weight: 1200g
Resolution: 0.001 g/cm3
Features:
(1)No need to open and close the lid; Simple operation;Shorter time; According to the specification of new materials laboratory.
(2)Show the percentage composition of mixed samples for researching and developing new materials.
(3)Automatically judge whether the sample is qualified or not;prompt alarm.
(4)Function of automatic zero tracking,buzzer warning,and overload warning.
(5)Function of solution compensation.either water or liquid can be used as medium.
(6)Function of setting actual water temperature,measuring medium density,and water proof medium density.
(7)Function of setting aerostatic buoyancy compensation and the bound of density.
(8)Adopt the completed high-capacity measurement accessories with the transparent injection moulding sink,which can resist wear,fall off,and corrosion.
(9)Adopt the completed special windproof and dustproof cover,which makes the structure convenient and durable.
(10)Interface of RS-232C is included.the printer of DE-40 is available to connect PC with instrument.
Standard Accessories:
Host,Sink,Test board,Tweezer,Thermometer,100G weight,Windproof and dustproof cover,A set of measuring grain accessories,A set of measuring floating body accessories,Power Transformer
Measurement Procedure of Non-hydroscopicity Products:
(1)Place sample on test board to measure weight in air,and then press ENTER button to
memory.
(2)Place the sample into water to measure weight in water,and then press the ENTER button to memory. Density value is displayed.
Measurement Procedure of Hydroscopicity Products:
(1)Place sample on the test board to measure weight in air,and then press the ENTER button to memory.
(2)Place sample that did waterproof treatment into water to measure weight in water, and
then press the ENTER button to memory. Density value is displayed.
Technical Specification:
| Brand |
Quarrz |
| Model |
AU-300V |
AU-600V |
AU-900V |
AU-1200V |
AU-120V |
AU-200V |
| Weight |
range |
0.005~300g |
0.005~600g |
0.01~900g |
0.01~1200g |
0.001~120g |
0.001~200g |
| Standard deviation |
0.005g |
0.005g |
0.01g |
0.01g |
0.001g |
0.001g |
| Density |
readability |
0.001 g/cm3 |
0.0001 g/cm3 |
| Testing Board |
ABS injection moulding |
Aluminum alloy die-casting moulding |
| range |
0.001~99.999g/cm3 |
0.0001~99.9999g/cm3 |
| Oil content resolution |
0.1% |
0.01% |
| Result display |
Oil content,density,oil total volume,oil volume can be read directly. |
| Measuring principle |
Archimede principle substitution method |
| Measuring time |
Around 10 to 60 seconds |
| Opening lid method for testing board |
Rapid unobstructed without lifting lid design |
| Water tank |
Completed injection moulding transparent PC water
tank(size:length15.3 cm×witdth10.7 cm×height9.3cm)
|
| Parameter setting |
Water temperature setting,measuring medium density setting,
lubricating oil medium density setting,air buoyancy setting.
|
| Calibration method |
Single key calibration,automatically detection |
| Standard components |
(1)host(2)water tank(3)testing board(4)tweezers(5)thermometers
(6)weight(7)windproof dustproof cover(8)power transformer
|
| Interface |
Standard RS-232 interface |
| Optional accessories |
AU-40 printer,data connecting wire |
| Power supply |
AC100V~240V 50HZ/60HZ (Europe standard) |
| Gross weight/size |
4.5kg/Length42.5 cm×Width17.5 cm×Height32.5cm |
