Place of Origin: | Dongguan |
Brand Name: | DahoMeter |
Certification: | CE,FCC |
Model Number: | HA-SSR-H |
Minimum Order Quantity: | one set |
---|---|
Price: | USD899 to 2699 per unit |
Packaging Details: | Standard exporting package |
Delivery Time: | 5 to 8 working days |
Payment Terms: | L/C, D/A, T/T, Western Union, MoneyGram |
Supply Ability: | 300 sets per month |
Product Name: | High Temperature Viscometer | Measuring Range (mPa.s): | 100 – 4M 21rotor:100-200K 27rotor:500-1M 28rotor:1K-2M 29rotor:2K-4M |
---|---|---|---|
Certification: | CE, ISO | Warranty Period: | 1 Year |
The high temperature rotary viscometer can measure the viscosity of solid materials at room temperature, which become fluid after being heated at high temperature, such as hot melt adhesive, asphalt, paraffin wax, polyethylene wax and other high temperature molten materials. With the advantages of accurate, fast, intuitive and simple measurement, the instrument is recommended by the adhesive industry standard compilation and selected by customers in related industries.
Main Features:
1. horizontal bubble front, sitting adjustment level can be very convenient.
2. have timing measurement function. Most of the samples we measured were typical non-Newtonian liquids with viscosity other than temperature and shear
In addition to the rate, it is also related to the length of the measurement. To make the measured data comparable, the measured time
It must be consistent.
3. the display accuracy of the measured data is two decimal places.
4. measurement data is displayed directly on the LCD screen without secondary calculation;
5. use small sample adapters, the amount of samples required for testing is very small, usually only 15-20 ml;
6. temperature range: room temperature plus 10℃-250℃(optional 300 heating furnace);
7. viscometer with RS232 interface can be directly connected to the micro printer.
Detailed Technical Parameters:
Model
|
RV-SSR-H (NDJ-1C) |
HA-SSR-H |
HB-SSR-H (NDJ-1F) |
Display | liquid-crystal display | ||
Speed (r/min) |
0.5/1/2/2.5/4/5/10/15/20/25/30/40/50/60/70/80/90/100,A total of 18 speeds | ||
Rotor
|
21,27,28,29 (standard configuration) Rotor No .0(optional) |
||
Measuring range
(mPa.s) |
50 - 2M 21rotor:50-100K 27rotor:250-500K 28rotor:500-1M 29rotor:1K-2M |
100 – 4M 21rotor:100-200K 27rotor:500-1M 28rotor:1K-2M 29rotor:2K-4M |
400 – 16M 21rotor:400-8M 27rotor:2K-4M 28rotor:4K-8M 29rotor:8K-16M |
K = 1,000; M=1,000,000 | |||
Test error | ±3% (Newtonian liquid) | ||
Repetitive error | ±1.5%(Newtonian liquid) | ||
Temperature control range | Room temperature plus 10℃-250℃ (300℃ optional) | ||
Temperature control accuracy | 0.1℃ | ||
Print interface | have |
