Universal tensile testing machine is widely used in most of industries: Rubber & Plastics; Metallurgical iron and steels; Manufacturing machinery; Electronic equipments; Automobile production; Textile fibers; Wire and cables; Packaging materials and footstuffs; Instrumentation; Medical equipments; Civilian nuclear energy; Civil aviation; Colleges and universities; Research laboratory; Inspection arbitration, technical supervision departments; Building materials and so on.
| Brand | HongTuo |
| Model | WDW-S |
| -005 | -01 | -02 | -05 | -1 | -2 | -5 | -10 |
| Capacity | KN | 0.05kN | 0.1 kN | 0.2 kN | 0.5kN | 1 kN | 2kN | 5kN | 10KN |
| KG | 5kg | 10kg | 20kg | 50kg | 100kg | 200kg | 500kg | 1000kg |
| lb | | | | | | | | |
| Structure | Double rail structure | Three double rail structure |
| Unit switching | G,Kg,lb,N,KN |
| Displacement unit switching | Inch cm mm |
| Test machine level | 1class |
| Effective force range | 0.4％～100％FS |
| Force accuracy | Within ±0.5% |
| Force decomposition | 1/200 000 |
| Force Power magnification | X1,X2,X5,X10,X20,X50,X100.,etc.Seven-speed automatic shifting |
| Displacement resolution | 0.05mm |
| Displacement accuracy | Within ±1% |
| Deformation measurement range | 2%～100%FS |
| Deformation indication accuracy | Within ±1% |
| Large deformation measurement range | (0～800)mm |
| Large deformation resolution | 0.05mm |
| Large deformation indication error limit | Within ±1% |
| Maximum test speed | 500mm/min；optional maximum 1000mm/min |
| Minimum test speed | 0.1mm/min |
| Speed accuracy | Within ±1% |
Beam travel Measuring height | standard | No grip testing stroke:920mm |
| optional | No grip testing stroke:1320mm |
| Fixture configuration | One set of tensile grip；can choose other grips |
| Returning method | Manual or automatic selection, automatically return after the test ends or manually return to the initial position |
| Stop method | 1.Maximum break value automatically stop 2.Upper and lower limit safety setting stop |
| Safety devices | 1.Mechanical limit switch protection 2.Emergency stop switch emergency brake |
| Overload protection | Over 10% of maximum load, automatic machine protection |
| Accessories | 1 power cord; 1 manual; 1 certificate |
| Optional accessories | Anti-splash device (protective door); printer;software |
| Powder supply | 220V.AC/ 50HZ; 110V.AC/60HZ |
| Main host size/ weight | Standard model:Length*Width*Height:450mm*400mm*1160mm / Around 50KG Heightening model:Length*Width*Height:450mm*400mm*1550mm / Around 55KG |
| Packing size / weight | Standard model:Length*Width*Height:550mm*500mm*1400mm / Around 73KG Heightening model:Length*Width*Height:550mm*500mm*1800mm / Around 78KG |
